CGI Sparta Impact-Resistant Windows & Doors | Guardian Hurricane Protection

Every Floridian understands the value and importance of impact-resistant windows and doors. However, did you know these technological miracles originated from a laboratory experiment accident by French chemist Edouard Benedictus in 1903? While conducting a glass flask coating experimentation, he unknowingly mixed plastic with a cellulose nitrate solution and acidentally dropped it. The glass did not break into pieces but remained intact and from then on, the rest was history.

Guardian Hurricane Protection, Florida’s leading hurricane solution provider understands the benefits of impact-resistant windows and doors and their importance in protecting residential properties in Florida.

Protect your property by investing in CGI Sparta impact-resistant windows & doors. Florida will always be a paradise but that sometimes comes with a price. Preventive protection and safeguarding against hurricanes, burglary, and weather elements can be achieved with impact-resistant windows and doors.

Benefits

• Convenience

• Improved Energy-Efficient Windows/Doors

• Increased Security

• Insurance Premium Discounts

• Investment Protection

• Long-Term Savings

• One-time Installation

• Peace of Mind

• Repair Cost Reduction

• Sound Proofing

• Storm Protection

• Ultraviolet Protection

• Verified for Quality

Features

• Finish: Powder-Coated White/Bronze

• Laminated Glass: Monolithic

• Interlayer: Clear/ Gray/Bronze/White

• Energy Coatings: High

• Assembly Screws: Stainless-steel

• Frame Depth: 2"

• Front Flange: 1/2"

• Design Pressures: Up to +55/-65 PSF

• Exterior: Glazed

• Easy Installation

• Florida Product Approval: HVHZ

• Muntin Types/Configurations: CGI Surface Applied/ Standard Patterned

• Warranties:

• 10-years: Frame/Component Parts

• 5-years: Laminated Glass Units

• 1-time: Transfer of Warranty

Single Hung SH 4100A

• Laminated Glass: 5/16"

• 1/8" Annealed: 0.090/ PVB

• 1/8" Heat Strengthened: 0.090/ PVB

• (Oriel) Sash Style: Standard/Proview

• Flange Size (Maximum): 53 1/8" x 78"

• Balances: Block/Tackle

• Sweep/Bottom Lock: Traditional

• Frame Corners: Gasket Sealed

• Integral Fin Frame: Optional

Horizontal Roller HR4110A

• Laminated Glass: 5/16"

• 1/8" Annealed: 0.090/ PVB

• 1/8" Heat Strengthened: 0.090/ PVB

• Lite Configurations: 2-3

• Frame Corners: Gasket Sealed

• Brass Rollers: Adjustable

• Weep Covers: Standard

• Maximum Sizes:

  • XO: 74" x 63"

  • XOX 1/3-1/3-1/3: 111" x 63"

  • XOX 1/4-1/2-1/4: 111" x 63"

Picture Window/ Architectural PW/AR 4120A

• Laminated Glass: 5/16"

• 3/16" Annealed: 0.090/ PVB

• 3/16" Heat Strengthened: 0.090/ PVB

• Maximum Size: 32 sq. ft. – 48" x 96"

• Corners: Silicone-Sealed

• Integral Fin Frame: Optional

• Architectural Shapes:

  • Half Circle

  • Eyebrow

  • Half Eyebrow

  • Arch

  • Trapezoid

PW 4120A Fixed Lite

• Minimum Flange Size: Width- 14 1/4 Height-11 1/4

• Maximum Flange Size: Width -48 Height -96

• Minimum Integral Fin Size: Width -13 1/4 Height -10 1/4

• Maximum Integral Fin Size: Width -47 Height -95

AR 4120A Fixed Lite

• Half-Circle

  • Minimum Flange Size: W-24 /H-12

  • Maximum Flange Size: W-96 /H-48

• Eyebrow (Arch Top Fixed)

  • Minimum Flange Size: W-24 /H-12

  • Leg Height: 6

  • Maximum Flange Size: W-48 /H-96

• Half-Eyebrow (Half-Arch)

  • Minimum Flange Size: W-14 1/4 /H-14 1/4

  • Leg Height: 8

  • Maximum Flange Size: W-48 /H-96

• Arch (Tombstone)

  • Minimum Flange Size: W-24 /H-18

  • Maximum Flange Size: W-48 /H-96

• Trapezoid

  • Minimum Flange Size: W-14,1/4 /H-12

  • Leg Height: 6

  • Maximum Flange Size: W-48 /H-96
